75 mm blücher rustfri a304

Viser 14 resultater

  • Close-up of a silver metal bottle neck/valve with threading and a barcode label
    75 x 50 mm Overgang excentrisk rustfri AISI304/EN1.4301 Blücher
    Overgang exentrisk, Ø50/75mm - Rustfrit stål
    208 kr inkl. moms
  • CAD drawing of a cylindrical pipe fitting with a top opening Ø75, a side branch Ø50 at a 45° angle, and overall dimensions including 66 mm width and 144 mm height; shows a secondary angled feature with a 94 mm measure and a 56 mm step, plus a bottom view illustrating the opening and collar.
    75 x 50 mm x 45° Grenrør rustfri AISI304/EN1.4301 Blücher
    Grenrør 45°, Ø75/50mm - Rør: Ø75mm, Grenrør: Ø50mm - Rustfrit stål
    402 kr inkl. moms
  • Cross-sectional drawing of a seal: outer diameter 94, inner bore 70, height 31, with rounded ends and a central rectangular body. Separate bottom view shows a similar profile.
    75mm bm mengeringssæt
    75mm bm mengeringssæt
    231 kr inkl. moms
  • Silvery metal pipe coupling with an open end and inner gasket visible
    75mmx15gr bm afl.bøjn aisi304
    75mmx15gr bm afl.bøjn aisi304
    151 kr inkl. moms
  • Technical line drawing of a pipe elbow fitting: 75 mm diameter, 70 mm height, with angled sections and a 30° bend; includes a 25 mm dimension reference. Also shows an isometric view of a ribbed cylindrical connector.
    75mmx30gr bm afl.bøjn aisi304
    75mmx30gr bm afl.bøjn aisi304
    151 kr inkl. moms
  • Technical drawing of a cylindrical bottle with a screw cap; Ø75 mm diameter, 1000 mm tall, 1 mm wall thickness (scale indicated).
    75x1000mm bm afl.rør aisi304
    75x1000mm bm afl.rør aisi304
    288 kr inkl. moms
  • Technical drawing of a 75 mm diameter duct elbow with a 45-degree bend and side outlet, with labeled dimensions.
    75x75x45g bm grenrør aisi304
    75x75x45g bm grenrør aisi304
    394 kr inkl. moms
  • Chrome-plated metal 90-degree plumbing elbow with a wide circular opening and label on the side
    Ø 75 mm x 45° Bøjning rustfri AISI304/EN1.4301 Blücher
    Bøjning 45°, Ø75mm - Rustfrit stål
    182 kr inkl. moms
  • Aluminum 90-degree pipe elbow fitting with a red identification label and inner gasketed opening used in plumbing or ductwork
    Ø 75 mm x 87,5° Bøjning rustfri AISI304/EN1.4301 Blücher
    Bøjning 87.5°, Ø75mm - Rustfrit stål
    244 kr inkl. moms
  • Technical drawing of a cylindrical container with a screw-on cap, shown in front and isometric views; diameter 75 mm, height 1500 mm.
    Ø 75 x 1500 mm Rør rustfri AISI304/EN1.4301 Blücher
    Afløbsrør af rustfri stål. Lige rør med 1 muffe.
    394 kr inkl. moms
  • Cross-section and isometric view of a tall cylindrical container with a screw-cap; Ø75, height 2000 units.
    Ø 75 x 2000 mm Rør rustfri AISI304/EN1.4301 Blücher
    Afløbsrør af rustfri stål. Lige rør med 1 muffe.
    521 kr inkl. moms
  • Longitudinal view of a 250 mm tall cylindrical container with Ø75 mm diameter and a screw-cap, showing an internal wavy seam and a stepped top seal.
    Ø 75 x 250 mm Rør rustfri AISI304/EN1.4301 Blücher
    Afløbsrør af rustfri stål. Lige rør med 1 muffe.
    105 kr inkl. moms
  • Shiny stainless steel exhaust pipe with an open circular end and a small label near the tip.
    Ø 75 x 250 mm Rør syrefast AISI316L/EN1.4404 Blücher
    Afløbsrør af rustfri stål. Lige rør med 1 muffe.
    135 kr inkl. moms
  • Technical drawing of a cylindrical container with a screw-cap, 75 mm diameter and 500 mm tall, with a mid-seam
    Ø 75 x 500 mm Rør rustfri AISI304/EN1.4301 Blücher
    Afløbsrør af rustfri stål. Lige rør med 1 muffe.
    163 kr inkl. moms
